THE BIG ONE
ZEMMLER® MULTI SCREEN® MS 4200-ST
The possibilities with a stationary ZEMMLER® MULTI SCREEN® MS 4200-ST are versatile and solution-oriented. We design your plant according to the local conditions. Therefore we offer you different solutions for feeding the double trommel, conveying the final products as well as the substructure.
In addition, we are able to manufacture an entire screening line for you with our plant engineering solutions. With a double trommel length of 4.20 m, the MS 4200-ST is ideal for use on medium-sized and large plants that process soil, rock, recycling, wood chips, etc.
360° View
Take a look at our double trommel screening machine from all perspectives:
click on the image and use the mouse to navigate to the side or down.
Technical data
Application areas
Options
Technical data
Capacity
(depending on material)
20 – 120 m³/h
Drive
Electric engine
Double trommel
Screening surface: 15,7 m² inner trommel, 16,0 m² outer trommel
Outer diameter: 2.000 mm
Trommel length: 4.200 mm
Wire screens
Interchangeable, meshes from 2 to 80 mm
Inner screen mesh: 80×170 mm (standard)
Fractions
3 fractions
2 fractions when single trommel
Weight
(depending on the equipment)
ca. 4 – 7,5 t
Transport dimensions (L x W x H)
4.850 x 2.500 x 3.200 mm
Application areas
Soil
Sand
Gravel
Stones
Compost
Green cuttings
Recycling material
Woodchips
Construction waste
Substitute fuels
Slag
Coal
Glass
and much more.
Options
Trommel designs
Single trommel
Double trommel
Additional equipment
Feeding unit with feed hopper and belt feeder
Conveyor belts
Electric box with control unit
Remote control
Special paintwork
Weather-/Dust protection roof
Drum magnet with chute
Working lights
Shear blade
Inner cage partition
and much more
